10" 100 WT WOOFER
- 8 Ohm
- Program Power : 200 w
- Voice Coil Diameter : 34 mm
- Sensitivity (1W/1m) : 92 db
Specification
Nominal Diameter
256 mm
Nominal Impedance
8 Ω
Nominal Power Handling (AES)
100 w
Program Power (AES)
200 w
Sensitivity (1W/1m)
92 db
Voice Coil Dia
34 mm
T/S Parameters
Resonant Frequency (Fs)
56 Hz
Electrical Q (Qes)
0.72
Mechanical Q (Qms)
4.85
Total Q (Qts)
0.62
Compliance Equivalent Volume (Vas)
43.78 lt
Moving Mass including air load (Mms)
35.77 g
Motor Strength (BL)
9.52 T-m
