18 PA 1000 C
| Key Features | |
| Program Power | 2000w |
| Voice Coil | 99.3mm |
| Sensitivity 1W/1M | 97db |
Specification
| Nominal Diameter | 475mm |
| Nominal Impedance | 8Ω |
| Gross Weight | 19.4kg |
| Nominal Power Handling(AES) | 1000w |
| Program Power | 2000w |
| Sensitivity (1W/1m) | 97db |
| Voice Coil Diameter | 99.3mm |
| Winding Material | CCAR |
| Former Material | Glass Fibre |
| Winding Type | Outside |
| Recommended Crossover | 8mm |
Parameters
| Resonant Frequency | FS | 41Hz |
| DC Resistance | Re | 5.8Ω |
| Electrical Q | Qes | 0.45 |
| Mechanical Q | Qms | 5.73 |
| Total Q | Qts | 0.42 |
| Compliance Equivalent Volume | vas | 250lt |
| Moving Mass including air load | Mms | 202.9g |
| Motor Strength | Bl | 25.8T-m |
| Voice Coil Inductance @ 1 KHz | Le | 1.2mH |
| Efficiency Bandwith Product | EBP | 91Hz |
